40 Channel Handheld CB Radio
The Uniden PRO401HH delivers the convenience of a handheld CB radio with the security of knowing you have the longest range possible so you can always stay in touch. It includes a low-power setting to conserve battery life and a high-power setting so you can extend your range when needed.
- 40 AM channels
- Condenser microphone.
- Ceramic filter: Delivers greater selectivity and reduces adjacent channel interference.
- AGC (Automatic Gain Control) for a constant sound level.
- Automatic modulation control for a constant audio transmit modulation level.
- Low distortion IC audio circuit.
- Automatic noise limiter to reduce pulse noise.
- TX Power select slide switch (HI = 4W; LOW = 1W)
- Antenna with BNC connector.
- External speaker jack and external MIC jack
- Jack for external power source and battery charger.
- Rechargeable (9 AA Ni-MH) or Alkaline (9 AA) batteries
- Internal battery select switch (alkaline or rechargeable)
| Weight | 0.95 lbs |
|---|---|
| Dimensions | 4.5 × 2.75 × 9 in |
| Manufacturer Part Number | PRO401HH |
Product Specification
Uniden PRO401HH Specifications
|
Channels
|
40 AM
|
|
Frequency Range
|
26.965 to 27.405 MHz
|
|
Frequency Control
|
Phase Locked Loop (PLL) synthesizer
|
|
Frequency Tolerance
|
±0.005%
|
|
Operating Temperature
|
14ºF to 131ºF (-10ºC to +55ºC)
|
|
Microphone
|
Electret Type
|
|
Input Voltage
|
13.8 V DC nom, 10.9VDC – 15.6VDC
|
|
Current Drain
|
TX full mod., 1.7A
|
|
RX
|
with max. audio output, 1.7A
|
|
Size
|
2.16 x 7.1 x 1.7 in (55 x 180 x 45 mm)
|
|
Weight
|
0.56 lbs (255 g)
|
Package Includes
Package includes:
- PRO401HH Mobile Radio
- Antenna
- DC Power Cable
- Wrist Strap
- Printed materials
