Dual Band and Dual Recording Receiver

SKU: 11764 Category: Discontinued

Dual Band and Dual Recording Receiver

The IC-R30 raises the bar on the DC to Daylight portable receivers!

Covering 0.1–3304.999 MHz*, the R30 portable receiver gives users the ability to decode multiple digital modes, as well as, traditional analog modes. The large LCD display makes operating the radio a breeze with a new intuitive user interface allowing you to see information from the dual receivers. With dual receive operation, you can simultaneously listen to two signals and record the activity to share the excitement with others. The supplied Li-Ion battery, BP-287, provides almost 8.5 hours of operating time (internal speaker, volume @ 20, GPS – on, Bluetooth® – off).
*Guaranteed range 0.1–3304.999 MHz

RX Frequencies:	0.1 – 3304.99MHz Decodes digital including P25, NXDN™, D-STAR RX analog including USB, LSB, CW, AM, FM & WFM
Channels:	2000 with 100 groups 200 auto memory write scan 100 scan skip channels 300 GPS memories
Bluetooth®	Built-in
GPS:	Built-in
Waterproof Rating:	IP57
Versions:	Cellular frequencies blocked or unblocked

Dual Band Operation, Including Dual Band Record

The R30 can receive on different bands and different modes. For example, users can monitor HF and UHF signals simultaneously. The R30 also allows users to scan for other active channels on the B band while receiving the main signal on the A band.

Individually record the audio of the two bands received while in the Dualwatch mode onto a microSD card* in the WAV format. Play back the recorded audio on the receiver or a PC. In addition, frequency, mode, S-meter reading, time, current position data and altitude can be saved with received audio.

Use a microSD card* for data storage. Recording/playback of received audio, RX history log, radio set tings and GPS logger data can all be loaded onto the microSD card.
*MSD card sold separately

High Speed Scan

The R30 scans approximately 200 channels per second in the A band and 150 channels per second in the B band. Quickly find and lock in to a desired signal.

R30’s variety of scan functions includes:

Near station scan – Using GPS location information and the Memory channels, the R30 can display and scan up to 50 stations within 160km from your current location, in proximity order. Just program the station’s position data in advance.
Auto memory write scan – Automatically stores received frequencies (up to 200Ch) during a Programmed scan.
Priority scan – Checks for signals on a frequency every 5 seconds, while operating on a VFO frequency or scanning.
Tone scan – Detects a sub-audible tone frequency or the DTCS code in a received signal.
And many more including: Program scan, Memory scan, Memory mode scan, Group scan, Group link scan.

GPS Receiver

The integrated GPS receiver displays your current position data, course, speed and altitude on the display. Save the GPS data in recorded audio files. The R30 can list up to 50 stations approximately 100 miles from your current location, as long as the station’s position data is programmed in advance in the memory channels.

Android™ and iOS™ Apps Available

Control your R-30 using your iOS™ or Android™ device! The RS-R30I for iOS™ devices, and RS-R30A for Android™ devices enable a wireless connection to the IC-R30, allowing you to remotely control VFO operation, memory channels, a variety of scans and the voice recording functions. Using the optional VS-3, Bluetooth® headset, the VS-3 and iOS™/Android™ device can be wirelessly connected to the IC-R30 at the same time. You can control the IC-R30∗ from the iOS™/Android™ device while listening to the received audio on the VS-3 optional Bluetooth® headset.
*The VS-3 plays either the app or R30 audio, not simultaneously.

Download from the Google Play™ Store | Download from Apple’s App Store >

Additional Features

2.3″ large LCD with intuitive user interface
Band scope function
Speech function reads out operating frequency and mode
8-character channel names
DTCS and CTCSS tone squelch
RF gain control (10 steps)
ATT function (3 steps)
Key lock function
Monitor function
Power save function (3 steps)
Clock

Weight	2.1 lbs
Dimensions	9 × 9 × 3.25 in
Brand	ICOM
Manufacturer Part Number	IC-R30

Product Specifications

Icom IC-R30 Specifications:

General

Frequency Coverage

A Band: 0.100000 − 821.999990
851.000000 − 866.999990,
896.000000 − 3304.999990 MHz*B Band: 108.000000 − 520.000000 MHz
* Depending on the receiver version. 0.100000–3304.999990 MHz guaranteed.

Mode

A band:
≤1300 MHz: FM, FM-N, WFM, AM, AM-N, SSB, CW, D-STAR (DV), P25, dPMR, NXDN,
>1300 MHz: DCR
FM, FM-N, WFM, AM, AM-NB band: FM, AM, D-STAR (DV), P25, dPMR, NXDN, DCR

Antenna impedence

1300 regular, 50 scan edges and 200 auto memory write

Number of channels

5, 6.25, 8.33*, 9*, 10, 12.5, 15,
20, 25, 30, 50,100, 125, 200 kHz
* Selectable depending on operating bands.

Tuning steps

±1.0ppm (25°C)

Battery life

2×R6 (AA) size Ni-MH or Alkaline cells

Power supply requirements

4.5V DC rated (4.5-6.3V with BC-196SA/SD, CP-18A/E)

Current drain (at 3.6 V DC)

AF rated power:	330 mA typical
Receive standby:	200 mA typical
Power saved: (FM mode single receive, voice recording OFF, GPS OFF, back light OFF)	100 mA typical

Operating temperature range

–20 °C to 60 °C, –4 °F to 140 °F

Dimensions (projections not included)

58 (W) × 143 (H) × 30.5 (D) mm
2.3 (W) × 5.6 (H) × 1.2 (D) in

Weight (approx.)

310 g, 10.9 oz (With antenna and BP-287 battery pack), 200 g, 7.1 oz (main unit)

Bluetooth®

Version: Bluetooth® Ver 4.2, Prole: HFP, HSP, SPP

GNSS

GPS, QZSS

Receiver

Receiving system

Triple conversion superheterodyne + Down converter (A band except WFM)
Double conversion superheterodyne (A band WFM, B band)

Intermediate frequencies

A band
1st IF: 266.65/266.7/266.75 MHz
2nd IF: 58.0500 MHz (Except WFM), 10.7000 MHz (WFM)
3rd IF: 0.4500 MHz (Except WFM)
B band
1st IF: 46.3500 MHz
2nd IF: 0.4500 MHz

Sensitivity (except spurious points):

SSB/CW (at 10 dB S/N)
0.495000 – 1.899990 MHz
1.900000 – 14.999990 MHz
15.000000 – 29.999990 MHz
50.000000 – 53.999990 MHz
144.000000 –147.999990 MHz
430.000000 – 449.999990 MHz
AM (at 10 dB S/N)
0.495000 – 1.899990 MHz
1.900000 – 14.999990 MHz
15.000000 – 29.999990 MHz
118.000000 – 136.999990 MHz
FM (at 12dB S/N)
28.000000 – 221.999990 MHz
222.000000 – 832.999990 MHz
833.000000 – 1299.999990 MHz
1300.000000 – 1999.999990 MHz
2000.000000 – 2699.999990 MHz
2700.000000 – 3304.999990 MHz
WFM (at 12 dB SINAD)
76.000000 – 107.999990 MHz
D-STAR (DV) (1% BER)
28.000000 – 29.999990 MHz
50.000000 – 53.999990 MHz
144.000000 – 147.999990 MHz
430.000000 – 449.999990 MHz
1260.000000 – 1299.999990 MHz
NXDN/dPMR/DCR (1% BER)
136.000000 – 173.999990 MHz
350.000000 – 379.999990 MHz
380.000000 – 511.999990 MHz
P25 (5% BER)
136.000000 – 173.999990 MHz
400.000000 – 469.999990 MHz
763.000000 – 832.999990 MHz
833.000000 – 869.999990 MHz

Less than 0.4 μV
Less than 0.25 μV
Less than 0.25 μV
Less than 0.25 μV
Less than 0.25 μV
Less than 0.32 μVLess than 2.2 μV
Less than 1.4 μV
Less than 1.4 μV
Less than 1.4 μVLess than 0.4 μV
Less than 0.56 μV
Less than 0.56 μV
Less than 1 μV
Less than 1.8 μV
Less than 10 μVLess than 1.8 μVLess than 0.71 μV
Less than0.71 μV
Less than 0.71 μV
Less than 1 μV
Less than 1 μVLess than 0.71 μV
Less than 1 μV
Less than 1 μVLess than 0. 4μV
Less than 0.56 μV
Less than 0.71 μV
Less than 0.71 μV

Available frequencies and modes differ, depending on A band and B band.

Selectivity

SSB/CW: More than 1.8 kHz/−6 dB
AM/FM: More than 12 kHz/−6 dB, Less than 30 kHz/−60 dB (below 1305 MHz), Less than 30 kHz/−40 dB (above 1305 MHz)
WFM: More than 150 kHz/−6 dB

Audio output power

Internal SP: More than 400 mW (16 load, at 10% distortion)
External SP: More than 200 mW (8 load, at 10% distortion)
